Welcome to Wenzhou Yixing Machinery Co.,Ltd.!

Single Screw DOuble Side Laminating Machine

YIHAI MACHINERY Co., LTD is located in Pingyang,wenzhou ,zhejiang province . It Is a innovative enterprises integrating research and development, production. Specialized in the production of air bubble film machine, laminating machine, stretch film machine,film blowing machine, bag making machine, printing machine and plastic packing machinery. Products are approved by CE certification.And the products are exported to overseas.


Detail

Inquery

Application:

Coating film such as LDPE or PP on surface of paper(as raw material for making disposable cup or shopping paper bags)non-woven fabric for making non-woven bag.

Optional equipment:

1.Chiller

2.Automatic Vacuum Feeder

3.Auto Changing Sieve

4.Scrap Reverse

5.PLC control system

  6.Corona treatment







Model

YHFM-800

YHFM-1100

YHFM-1300

YHFM-1600

YHFM-1800

YHFM-2000

T-Die Length

1000mm

1300mm

1500mm

1800mm

2000mm

2200mm

Max. width film

800mm

1100mm

1300mm

1600mm

1800mm

2000mm

Speed

110m/min

110m/min

110m/min

110m/min

110m/min

110m/min

Film Thickness

0.06-0.15mm

0.06-0.15mm

0.06-0.15mm

0.06-0.15mm

0.06-0.15mm

0.06-0.15mm

Screw Dia.

φ85mm

φ90mm

φ95mm

φ100mm

φ105mm

φ110mm

Max. dia. rewinding

1200mm

1200mm

1200mm

1200mm

1200mm

1200mm

Material diameter

1200mm

1200mm

1200mm

1200mm

1200mm

1200mm



Product Application

Yihai designs and manufactures extrusion coating  machine lines on the strength of a thorough expertise in the co-extrusion of special polymers - customized and modular layout to meet the demand for special products; - chill-roll unit with precise temperature control - rapid cooling system - special winders and unwinders suitable for any final application.



Specification:

Model

YHFM-800

Length of mold

1000mm

Width of film

800mm

Speed

150m/min

Thickness laminating

0.06-0.15mm

Screw Diameter

φ85mm

Max.Diameter rewinding

1200mm

Material Diameter

1200mm

Total Power

60KW

L*W*H

13*11*3.2m



 Product Application

1.Paper cups : PE coated paper

2.Non woven bags : Non woven fabric + PE

3.Release paper : Release paper + PE

4.Sugar packages : Thin paper + PE

5.Baby diaper : Thin non woven +PE
